Design specification |
ASME B16.34 |
Connection standard |
ASME B16.5, EN 1092-1, GB/T 9124, ASME B1.20.1 |
Inspection standard |
ISO 10497, GB/T 26480, API 598 |
Size range |
NPS 1~24 / DN 25 ~ 600 |
Pressure level |
ASME Class 150~1500 / PN 6~250 |
Applicable temperature |
-46℃~425℃ |
Connection method |
1) Flange connection RF, RTJ; 2) Butt welding connection BW 3) Socket welding SW; 4) Threaded connection NPT, Rc |
Structural type |
Casting, welding |
Shell material |
WCB, LCB, A105, LF2, CF8, CF3, CF8M, CF3M, F304, F304L, F316, F316L |
Actuator |
Handwheel, manual actuator, pneumatic actuator, electric actuator |
